DIW-75 Digital Torque Wrench, 3/8" Drive, Capacity: 680 lbf-in
Price: $ 1,402.00
Digital Torque Wrench with USB Output
1/4", 3/8" or 1/2" Drive
Capacity: up to 87 ft-lbs
Wrench head swivels 300
DIW Digital Torque Wrench | DIW is a lightweight digital torque wrench that tightens or loosens bolts up to 1040 lbf-in. The wrench head swivels 300 and can be used in tight places. Youll get consistent readings no matter where or how the wrench is gripped because the torque sensor is centered on the drive and not up in the handle. Torque controlled wrenches can also be evaluated by comparative tests on a given fastener. Both breakaway and loosen tests can be performed. Rugged enough to be used in production. Wrench head swivels 300  This tester has an accuracy of 0.5%, 1 LSD. It offers a programmable setpoint for uniform tightening or Go/No Go testing and also provides peak data for SPC (statistical process control) via the RS232 port. Consistent readings no matter where the wrench is gripped because the torque sensor is centered on the drive.
 |
  Features  Includes NIST calibration Certificate | Wrench head swivels 300 | Available in lbf-in, lbf-ft, Kgf-cm and N-m (selectable) | Peak, Real Time and Peak Down measuring mode (selectable) | 400 data memory for recall or for SPC download | Programmable High and Low setpoints with both audible beep and Green/ Red LED indicator for uniform torque tightening or GO/NO GO testing | Both CW and CCW operation |
| RS-232 output for SPC capability (peak data only) | CW stepless one-way clutch adapter, AC charger and carrying case included. | Runs on internal NiCad batteries (8 hour use) | DIW is sold as a kit including carrying case and AC adapter/charger | Ergonomic, light weight, rugged metal construction | ISO/IEC 17025 Long-form Certificate & Test Data is optionally available | 2 Year Warranty |
|
Photo Gallery - click any photo to enlarge Force Ranges Model | Capacity | Drive Size | DIW-15 | 3.0 130.0 lbf-in
3.0 150.0 kgf-cm
0.30 15.00 N-m | 1/4" | DIW-20 | 3.0 180.0 lbf-in
3.0 200.0 kgf-cm
0.30 20.00 N-m | 3/8" | DIW-75 | 3.0-660.0 lbf-in
0.30-55.00 lbf-ft
3.0-750.0 kgf-cm
0.30-75.00 N-m | 3/8" | DIW-120 | 30-1040 lbf-in
3.0-87.0 lbf-ft
30-1200 kgf-cm
3.0-120.0 N-m | 1/2" | |
| Accuracy 0.5% F.S., 1 LSD | |
| |
Related Products |
SW-1
Data Acquisition Software for Force Gauges & Torque Gauges |  | Full SPC and graphing capabilities Automates your data collection Provides a running log of all measurements along with a chart of the data as well as statistical information | |
Specifications | Accuracy | 0.5%, 1 LSD | | Sampling Frequency | 100 Hz (100 samples/sec) | | Display Update Rate | 5 Hz (5 times/sec) | | RS232 Throughput | 80 Hz, max (80 sample/sec,max) | | Memory | 400 data memory for recall or for SPC download | | Warranty | 2 years |
