ADS40 Dial Torque Wrench (3/8" Sq Dr)

Price: $ 530.00

DS Dial Torque Wrench

Ranges up to 1500 Lbf-ft

Non-length dependent

DS Dial Torque Wrench

Dial wrenches are typically used as a quality control instrument to verify or monitor torque. However, some customers find them a resourceful production tool. In all cases, our dial wrenches are found to offer unmatched performance for several reasons. First, they are simple and easy to calibrate. Second, they incorporate an overload protection device to prevent over-torque and damage to parts or to the wrench. Third, our dial wrenches are non-length dependent, which means an operator can hold the wrench anywhere along the handle and the exact torque will be achieved. Lastly, the wrench offers a built-in ratchet mechanism.

Features

Dual scale in American and S.I. units. Single scale models are available upon request.

Exclusive built-in ratchet mechanism.

Fine main and memory pointers provide accurate readings.

Quality constructed for accuracy and reliability with an attractive abrasive resistant finish for longer life and ease in identification.

Standard double-ended spindle ratchet mechanism allows for left handed torque applications.

Single-end spindles available upon request.

Lightweight aluminum handle (w/non-slip grip) for improved balance. Scuff-resistant non-slip finish.

Mechanical stop provides overload protection to 125% of full scale.

Recessed dial minimizes dial breakage.

Dial wrench models are available in a wide variety of torque ranges, from 7 lbf.in - 1500 lbf.ft. Select a dial wrench that fits your toque range requirement.

Photo Gallery - click any photo to enlarge

Force Ranges

Model	Capacity	Resolution	Square Drive	Light Signal
ADS4	7 - 35 lbf.in 0.8 - 4 N.m	1 lbf.in 0.1 N.m	1/4"	*
ADS8	14 - 70 lbf.in 1.6 - 8 N.m	1 lbf.in 0.25 N.m	1/4"	*
ADS12D	24 - 120 lbf.in 2.4 - 12 N.m	2 lbf.in 0.5 N.m	1/4"	*
ADS12A	24 - 120 lbf.in 2.4 - 12 N.m	2 lbf.in 0.5 N.m	3/8"	*
ADS25	48 - 240 lbf.in 5 - 25 N.m	10 lbf.in 1 N.m	3/8"	*
ADS25F	4 - 20 lbf.ft 5 - 25 N.m	0.5 lbf.in 1 N.m	3/8"	*
ADS40	72 - 360 lbf.in 8 - 40 N.m	10 lbf.in 1 N.m	3/8"	*
ADS40F	6 - 30 lbf.ft 8 - 40 N.m	1 lbf.in 1 N.m	3/8"	*
BDS80A	12 - 60 lbf.ft 16 - 80 N.m	1 lbf.in 2 N.m	3/8"	No
BDS80AS	12 - 60 lbf.ft 16 - 80 N.m	1 lbf.in 2 N.m	3/8"	Yes
BDS80E	12 - 60 lbf.ft 16 - 80 N.m	1 lbf.in 2 N.m	1/2"	No
BDS80ES	12 - 60 lbf.ft 16 - 80 N.m	1 lbf.in 2 N.m	1/2"	Yes
BDS160	24 - 120 lbf.ft 32 - 160 N.m	2 lbf.in 2.5 N.m	1/2"	No
BDS160S	24 - 120 lbf.ft 32 - 160 N.m	2 lbf.in 2.5 N.m	1/2"	Yes
BDS200	30 - 160 lbf.ft 40 - 200 N.m	5 lbf.in 5 N.m	1/2"	No
BDS200S	30 - 160 lbf.ft 40 - 200 N.m	5 lbf.in 5 N.m	1/2"	Yes
CDS400S	60 - 300 lbf.ft 80 - 400 N.m	10 lbf.in 10 N.m	3/4"	Yes
DDS800S	120 - 600 lbf.ft 160 - 800 N.m	20 lbf.in 20 N.m	3/4"	Yes
EDS1400	200 - 1000 lbf.ft 280 - 1400 N.m	25 lbf.in 25 N.m	1"	Yes
EDS2000	300 - 1500 lbf.ft 400 - 2000 N.m	50 lbf.in 50 N.m	1"	Yes

Note:

* SPECIAL ORDER
All Light Signal Wrenches use standard size batteries
All ADS - EDS wrenches available in single scale models
ADS and BDS models are supplied with a protective plastic case
EDS Models available with single or double-end, but not with a ratchet end
For Single-End Spindle select "SE" option in Buy Now

Related Products

DTW
Electronic Torque Wrench

CW and CCW operation

Buzzer and LED indicator for the pre-settable target torque

Extension Spanners

Extension Adapters

Order Online
Check the items you would like to order then click "Add To Cart". Items typically ship within 1 Week
	Product	Price
	ADS40 Dial Torque Wrench (3/8" Sq Dr)	$530.00
	Accessories	Price
	20-A96122 Extension Adapter (3/8 Sq Dr to Dovetail)	$397.00
	20-A96112 Extension Adapter (3/8 Sq Dr to German 9x12)	$269.00
	20-A96102 Extension Adapter (3/8 Sq Dr to 16mm Spigot)	$237.00
	20-A96123 Extension Adapter (1/2 Sq Dr to Dovetail)	$422.00
	20-A96113 Extension Adapter (1/2 Sq Dr to German 9x12)	$282.00
	20-A96103 Extension Adapter (1/2 Sq Dr to 16mm Spigot)	$250.00
